10W Flexible Neon Light Strip IP65 2020
| CRI | >80 | ||||
| Delivered flux | 1000 lm/m | ||||
| Delivered efficiency | 100 lm/W | ||||
| Input power | 10W/m | ||||
| Supply voltage | 24V DC | ||||
| Light colour/CCT | 3000K/4000K/6000K | ||||
| Beam angle | diffuse | ||||
5-YEAR WARRANTY
5-YEAR WARRANTY
| CRI | >80 | ||||
| Delivered flux | 1000 lm/m | ||||
| Delivered efficiency | 100 lm/W | ||||
| Input power | 10W/m | ||||
| Supply voltage | 24V DC | ||||
| Light colour/CCT | 3000K/4000K/6000K | ||||
| Beam angle | diffuse | ||||
PARAMETER
| IP rating | 65 | ||||
| Ik rating | 3 | ||||
| Source type | Hight power LED | ||||
| Source life time | >50,000h at 25°C ambient temperature | ||||
| CRI | >80 | ||||
| Step McAdam | 3 | ||||
| Source flux | 1200 lm | ||||
| Source efficiency | 120 lm/W | ||||
| Delivered flux | 1000 lm | ||||
| Delivered efficiency | 100 lm/W | ||||
| Input power | 10W | ||||
| Supply voltage | 24V DC | ||||
| Insulation Class | insulation class III | ||||
| Power supply | - | ||||
| Material | Flexible Printed Circuit+silica gel | ||||
| Light colour/CCT | 3000K/4000K/6000K | ||||
| Beam angle | diffuse | ||||
| Mounting | surface mount | ||||
| LED Qty | 120 | ||||
TEMPERATURE LIMITS
Working temperature: -30C° to +50C°
Storage temperature: -50C° to +80C°
LIGHT CONTROL
ON/off
CONSTRUCTION
Flexible printed circuit board, Double sided adhesive tape on the back of the light strip,Outdoor IP65 waterproof, UV resistant pure silicone integrated molding extrusion process
WARRANTY
• 5-year limited system warranty standard
• Warranty does not cover product failure due to an overvoltage event (power surge)
• For installations where power surge may be possible, NICOR recommends installing additional surge protection at the electrical distribution panel
SPECIFICATIONS
TECHNICAL DRAWING
PHOTOMETRICS
The Optilux 10W IP65 Flexible Neon LED Strip Light is a professional-grade linear lighting solution designed for both indoor and outdoor use. With a sleek silicone encapsulated body, high brightness output, and excellent bending flexibility, this LED neon strip is ideal for architectural contour lighting, commercial signage, and landscape decorative lighting.
The OPTILUX 10W Flexible Neon Light Strip offers vibrant, uniform lighting with a flexible silicone casing, ideal for architectural outlines, signage, and decorative accents. Rated IP65 for outdoor use, it combines durability with smooth light diffusion. Easily cuttable and bendable, it adapts to various creative lighting layouts. Available in fixed color temperatures, customizable from 3000K to 6000K upon request.
Featuring uniform light emission with no LED hotspots, this strip mimics traditional neon lights while offering energy efficiency, long lifespan, and IP65-rated weatherproof protection, making it a perfect replacement for glass neon tubes.
Neon-style continuous glow, no dotting or visible diodes
High resistance to UV, salt, and harsh environments
Low heat emission, safe for touch and enclosed use
Flexible installation on curved, straight, or cornered surfaces
Available in single color, tunable white, RGB, and RGBW formats
Fully compatible with DMX / DALI / PWM / 0-10V control systems
Perfect for a wide range of decorative and functional lighting environments:
Architectural façade outlines and rooflines
Building signage and logo backlighting
Landscape and garden lighting
Shopping malls and retail storefront displays
Theme parks and public squares
Interior ambient contour lighting for ceilings, walls, and furniture
Marine or automotive decorative lighting
Its durable waterproof design makes it suitable for both indoor and outdoor projects requiring vivid, customizable, and weatherproof strip lighting solutions.
Professional manufacturer with over 10 years in LED linear lighting
Custom length, color, connector & controller support
Stable driver compatibility and installation accessories
Strict QC with waterproof testing and aging test
Excellent project support with OEM & ODM capability
A1: Yes, it's IP65-rated and suitable for weather-exposed installations.
A2: Yes, with a compatible dimming driver.
A3: Yes, it features flexible silicone material for creative layouts.
Need reliable and flexible neon strip lighting for your next project? Contact Optilux today for samples, pricing, or tailored strip lighting solutions. We offer expert consultation for architects, installers, and lighting designers worldwide.
