3W IP65 LED Square Spotlight
3W 2.5 in. CCT 3000-6000K IP65 Square Spotlights
3W 2.5 in. CCT 3000-6000K IP65 Square Spotlights
3W IP65 LED Square Spotlight
3W 2.5 in. CCT 3000-6000K IP65 Square Spotlights
3W 2.5 in. CCT 3000-6000K IP65 Square Spotlights

3W 2.5 in. CCT 3000-6000K IP65 Square Spotlights


CRI>80
Delivered flux240lm
Delivered efficiency80 lm/W
Input power3W
Supply voltage220V AC
Light colour/CCT3000K/4000K/6000K
Beam angle15°/24°/36°/60°


RECOMMENDED BUNDLES

PARAMETER

IP rating65
Ik rating8
Source typeHight power LED
Source life time>50,000h at 25°C ambient temperature
CRI>80
Step McAdam3
Source flux360 lm
Source efficiency120 lm/W
Delivered flux240 lm
Delivered efficiency80 lm/W
Input power3W
Supply voltage220V AC
Insulation Classinsulation class III
Power supplyBuilt in constant current
Materialaluminium
Light colour/CCT3000K/4000K/6000K
Beam angle15°/24°/36°/60°
Mountingsurface mount
Reflector colorblack
FinishingGrey/Black


TEMPERATURE LIMITS

Working temperature: -30C° to +50C°

Storage temperature: -50C° to +80C°


LIGHT CONTROL

ON/off

CONSTRUCTION

Die cast aluminum shell, surface sandblasting treatment, anti-corrosion and rust prevention, adjustable bracket, tempered glass, stainless steel screws

WARRANTY

• 5-year limited system warranty standard

• Warranty does not cover product failure due to an overvoltage event (power surge)

• For installations where power surge may be possible, NICOR recommends installing additional surge protection at the electrical distribution panel


SPECIFICATIONS

TECHNICAL DRAWING


PHOTOMETRICS

Description


The OPTILUX 3W square LED spotlight offers compact and efficient outdoor accent lighting. With IP65 waterproof protection and a corrosion-resistant aluminum body, it is ideal for illuminating pathways, signage, and garden landscapes. Offered in fixed color temperatures from 3000K to 6000K to suit different project requirements.


Optilux 3W Square LED Spotlight Applications


  • Landscape and garden lighting

  • Building façade and architectural highlight

  • Pathways and courtyards

  • Signboard and wall wash illumination

  • Accent lighting for hotels, villas, and residential exteriors


Whether for commercial or residential outdoor projects, this spotlight delivers stable performance with low power consumption and long service life.


Why Choose Optilux?


  • Over 10 years of experience in LED outdoor lighting manufacturing

  • Strict quality control with CE, RoHS certifications

  • Flexible OEM/ODM customization support

  • Fast response and tailored lighting solutions


FAQ


Q1: Is this spotlight weather-resistant?

A1: Yes, with an IP65 rating, it’s designed for outdoor use in all weather conditions.


Q2: Can the color temperature be adjusted?

A2: No, but it can be customized to a fixed CCT (3000K, 4000K, or 6000K) before production.


Q3: Is it suitable for garden path lighting?

A3: Absolutely, its focused 3W output is ideal for accenting pathways and small outdoor areas.


Looking for compact, durable, and efficient outdoor spotlights? Contact Optilux today for bulk pricing, technical consultation, or custom requirements. Let us light up your project with precision and reliability.
