10W Trimless Mini Round Recessed Spotlights

CRI		>90
Delivered flux		800 lm
Delivered efficiency		80 lm/W
Input power		10W
Supply voltage		110~240V AC
Light colour/CCT		3000K/4000K/6000K
Beam angle		15°/24°/36°

Inquire Now

OPTIMSL13BR10W220VB

PARAMETER

IP rating		54
Ik rating		8
Source type		Hight power LED
Source life time		>50,000h at 25°C ambient temperature
CRI		>90
Step McAdam		3
Source flux		1200 lm
Source efficiency		120 lm/W
Delivered flux		800 lm
Delivered efficiency		80 lm/W
Input power		10W
Supply voltage		110~240V AC
Insulation Class		Insulation class III
Power supply		Lifud driver constant current
Material		Aluminum
Light colour/CCT		3000K/4000K/6000K
Beam angle		15°/24°/36°
Mounting		Recessed Mounted
Reflector color		Matte Black/Matte White/Sand Silver
Finishing		White and Sliver

TEMPERATURE LIMITS

Working temperature: -30C° to +50C°

Storage temperature: -50C° to +80C°

LIGHT CONTROL

ON/off, optional DALI dimming

CONSTRUCTION

•The trimless downlight utilizes a one-piece die-cast aluminum body with thermal-conductive fins, ensuring rapid heat dissipation and invisible ceiling integration.

• Certified for direct contact with insulation

WARRANTY

• 5-year limited system warranty standard

• Warranty does not cover product failure due to an overvoltage event (power surge)

• For installations where power surge may be possible, NICOR recommends installing additional surge protection at the electrical distribution panel

SPECIFICATIONS
