15W G80 CCT 2700-6000K Globe Bulbs
| CRI | >80 | ||||
| Delivered flux | 1800lm | ||||
| Delivered efficiency | 120 lm/W | ||||
| Input power | 15W | ||||
| Supply voltage | 110V/220 AC | ||||
| Light colour/CCT | 3000K/4000K/6000K | ||||
| Beam angle | diffuse | ||||
5-YEAR WARRANTY
5-YEAR WARRANTY
| CRI | >80 | ||||
| Delivered flux | 1800lm | ||||
| Delivered efficiency | 120 lm/W | ||||
| Input power | 15W | ||||
| Supply voltage | 110V/220 AC | ||||
| Light colour/CCT | 3000K/4000K/6000K | ||||
| Beam angle | diffuse | ||||
PARAMETER
| IP rating | 40 | ||||
| Ik rating | 6 | ||||
| Source type | Hight power LED | ||||
| Source life time | >50,000h at 25°C ambient temperature | ||||
| CRI | >80 | ||||
| Step McAdam | 3 | ||||
| Source flux | 2100 lm | ||||
| Source efficiency | 140 lm/W | ||||
| Delivered flux | 1800 lm | ||||
| Delivered efficiency | 120 lm/W | ||||
| Input power | 15W | ||||
| Supply voltage | 110V/220V AC | ||||
| Insulation Class | insulation class III | ||||
| Power supply | Built in constant current | ||||
| Material | Plastic aluminum | ||||
| Light colour/CCT | 3000K/4000K/6000K | ||||
| Beam angle | diffuse | ||||
| Base | E26/E27/E14 | ||||
| Reflector color | - | ||||
| Finishing | white | ||||
TEMPERATURE LIMITS
Working temperature: -30C° to +50C°
Storage temperature: -50C° to +80C°
LIGHT CONTROL
ON/off,Phase dimming
CONSTRUCTION
The outermost shell is made of plastic, the inside is made of aluminum, and the PC diffusion lampshade
WARRANTY
• 5-year limited system warranty standard
• Warranty does not cover product failure due to an overvoltage event (power surge)
• For installations where power surge may be possible, NICOR recommends installing additional surge protection at the electrical distribution panel
SPECIFICATIONS
TECHNICAL DRAWING
PHOTOMETRICS
Description
The OPTILUX G80 15W globe bulb features a decorative round shape with high luminous efficiency and a uniform glow, perfect for hospitality and home interiors. It fits standard E27 bases and is offered in fixed color temperatures from 2700K to 6000K to suit different atmospheres.
· Q1: What socket base does it use?
A1: E27 standard base.
· Q2: Is it flicker-free?
A2: Yes, when used with a compatible driver.
· Q3: Can it be used with dimmers?
A3: Yes, dimmable versions are available.
